3.5 Inch TFT LCD Display High Definition Vibrant Colors with HX8238D Driver
TFT LCD Display Description:
Experience unparalleled visuals with our 3.5 Inch TFT LCD Display. Engineered for precision, it boasts a high-definition resolution of 320(RGB)×24024-bit, delivering a vivid display with a wide color spectrum of 16.7M. The results are rich, vibrant visuals that truly bring your content to life.
Our TFT LCD Display features an interface that supports RGBISERIALRGBICCIR656/CCIR601, ensuring smooth data transmission for a seamless visual experience. It operates on A-Si technology, providing a reliable performance over its lifespan. Operating in a Normally White display mode, it offers a 6 O'clock gray viewing direction, assuring excellent color fidelity and contrast.
Though compact (LCM dimensions: 76.9063.93.26mm), our 3.5 Inch TFT LCD Display doesn't compromise on display size with an active area of 70.08 X 52.56mm. Please note that this display does not come with a TSP.
Our LCD display is driven by the HX8238D Driver LC, ensuring consistent and robust performance. It features a surface treatment of Haze 20%, providing a gentle, glare-free viewing experience. With a 12 O'clock viewing direction, enjoy clear and undistorted views from the top. The display houses 6 LEDs, with the precise weight to be provided later (TBD).
Choose our 3.5 Inch TFT LCD Display for a superior blend of visual quality, durability, and performance!
TFT LCD Display Applications:
1. Automotive Applications: In automotive electronics, Small LCD Displays are used in onboard diagnostics systems, GPS navigation systems, rear-view cameras, and digital speedometers. Their high brightness and contrast ratio ensure excellent readability even under bright ambient light conditions.
2. Consumer Electronics: In the realm of consumer electronics, these displays are used in personal devices like smart home systems, fitness trackers, and smartwatches. They provide high-resolution images and consume less power, making them efficient and user-friendly.
3. Point of Sale Systems: Small LCD Displays are widely used in point of sale (POS) systems. These systems require compact, clear, and durable displays, and these LCDs are ideal for showing customer transactions, product information, and digital signatures.
TFT LCD Display Parameters:
| Name: | 3.5 Inch TFT LCD Display | Interface: | RGBISERIALRGBICCIR656/CCIR601 |
| Display Format: | 320(RGB)×24024-bit | Display Color: | 16.7M |
| Technology Type: | A-Si | Display Spec.: | 0.073 X0.219 |
| Display Mode: | Normally White | Driver LC: | HX8238D |
| Surface Treatment: | Haze 20% | Viewing Direction: | 12 O'clock |
| Gray Viewing Direction: | 6 O'clock | LCM(W X HxD)(mm): | 76.90*63.9*3.26 |
| Active Area(mm): | 70.08 X 52.56 | With /Without TSP: | Without TSP |
| Weight (g): | TBD | LED Numbers: | 6 LEDs |
